Features

●Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade.

●Integrated OAM remote configuration and maintenance function.

●Support rich QinQ VLAN functions and IGMP Snooping multicast features.

●Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.

●Support NAT, Firewall function.

●Support IPv4 and IPv6 dual stack.

●Integrated line testing compliant with GR-909 on POTS.

Specification

Technical Item	1GE+1FE+1POTS XPON ONU
PON Interface	1 E/GPON port Wavelength:Tx1310nm,Rx 1490nm SC/UPC connector Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM
LAN Interface	1 x 10/100/1000Mbps and 1 x 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
POTS Interface	1 FXS, RJ11 connector Support: G.711/G.723/G.726/G.729 codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according to GR-909
LED	For Status of Power, PON, LOS,Phone,INTERNET,LAN 1,LAN2
Operating Condition	Temperature: 0℃～+50℃ Humidity: 10%～90%（non-condensing）
Storing Condition	Temperature : -30℃～+60℃ Humidity :10%～90%（non-condensing）
Power Supply	DC 12V,1A/1.5A
Power Consumption	≤7W
Dimension	110mm×90mm×25mm（L×W×H）

Network Construction

XPON 1GE+1FE+1POTS ONU (5)

Ordering Information

Product Name	Product Model	Descriptions
XPON HGU	1GE+1FE+POTS	1GE,1FE Ethernet interface,1RJ11,1 XPON interface, plastic casing, external power supply adapter
