Model type | Compact-SFP-1.25G-LR | Brand | HTF |
Encapsulation | CSFP | Data Rate | 1250Mb/s |
Wavelength | 1490/1310(nm) | Reach | 20KM |
Interface | BIDI LC/UPC | Protocols | SFF-8472 MSA Compliant |
Cable Type | SMF（9/125µm） | DDM Support | Yes |
Tx power | -9~-3dBm | Rx Sens | <-20dBm |
Commercial Temperature Range（oC） | Commercial: 0 ~ +70 | Optical Components | 1490nm DFB laser transmitter and PIN photo-detector |
Applications for 1.25G LR 10KM CSFP Module
◇Switch to Switch Interface
◇Gigabit Ethernet
◇Point to Point FTTH Application
◇Switched Backplane Applications
◇Router/Server Interface
◇Other Optical Links
General Description
The 1.25G LR 10KM CSFP Module consists of 2-channel Bi-directional Optical Transceiver unit with five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the DFB laser and the PIN photo-detector .The module data link up to 20km in 9/125um single mode fiber. Conventional SFP will function when plugged into a C-SFP socket, at the same time no damage to C-SFP and host board if C-SFP module is plugged into a conventional SFP socket
Digital Diagnostic Functions
1.25G LR 10KM CSFP Module
The following digital diagnostic characteristics are defined over the Recommended Operating Environment unless otherwise specified. It is compliant to SFF8472 Rev10.2 with internal calibration mode. For external calibration mode please contact our sales staff.
Parameter | Symbol | Min. | Max | Unit | Notes |
Temperature monitor absolute error | DMI_Temp | -3 | 3 | degC | Over operating temp |
Supply voltage monitor absolute error | DMI_VCC | -0.15 | 0.15 | V | Full operating range |
RX power monitor absolute error | DMI_RX | -3 | 3 | dB | |
Bias current monitor | DMI_bias | -10% | 10% | mA | |
TX power monitor absolute error | DMI_TX | -3 | 3 | dB |
FAQ
1、Question：What is the maximum transmission distance of the gigabit optoelectronic module? What is the maximum transmission distance of the 10,000 megabit optoelectronic module?
Answer：The gigabit optoelectronic module is generally connected with Cat6 network cable, and its maximum transmission distance is 100m; The 10 gigabit optoelectronic module is generally connected to the Cat6a network cable, and its maximum transmission distance is 30m.
2、Question：Do both the gigabit and 10,000 gigabit modules support hot plug?
Answer：Yes, but please do not operate it frequently, otherwise it will affect the service life of the optoelectronic module.
3、Question: Is it possi le to order 500 to 1000 of these??
Answer: Of course! Please contact us at "sales2@HTF.com", we will offer you a reduced price for this bulk order. Look forward to cooperate with you.
