Fiber optic transceivers 622M Bidirectional 80km ZR Transceiver
Model type | SFP-622M-BIDI-80KM | Brand | HTF |
Encapsulation | SFP | Data Rate | 622M |
Wavelength | 1490nm-TX/1550nm-RX 1550nm-TX/1490nm-RX | Reach | 80KM |
Cable Type | SMF（9/125µm） | Interface | BIDI LC optical connector |
Tx power | -3~2dBm | Rx Sens | <-28dBm |
Optical Components | 1490nm DFB laser transmitter and PIN photo-detector | ||
Part Number Ordering Information
Part Number | Data Rate (Mb/s) | Wavelength (nm) | Transmission Distance(km) | Temperature (oC) (Operating Case) |
HTSF-B6M4955ZC | 622 | 1490Tx/1550nmRx | 80km SMF | 0~70 commercial |
HTSF-B6M4955ZE | 622 | 1490Tx/1550nmRx | 80km SMF | -10~80 Extended |
HTSF-B6M4955ZI | 622 | 1490Tx/1550nmRx | 80km SMF | -40~85 Industrial |
6 Tips for selecting optical modules
1. Identify new optical modules and used optical modules.
2. Select the appropriate type of optical module as required.
3. See the compatibility between the optical module and the device.
4. Consider the temperature adaptability of the optical module.
5. Consider whether the parameters of the optical module meet the requirements of the device.
※ 850nm (MM, multimode, low cost but short transmission distance, generally only 500M);
※ 1310nm (SM, single mode, large loss during transmission but small dispersion, generally used for transmission within 40KM);
※ 1550nm (SM, single mode, low loss during transmission, large dispersion, generally used for long-distance transmission above 40KM, far-reaching direct transmission of 120KM without relay).
6. According to the years of the optical module after-sales service to judge.
FAQ
1、Question: Is it possi le to order 400 to 500 of these??
Answer: Of course! Please contact us at "sales2@htfuture.com", we will offer you a reduced price for this bulk order. Look forward to cooperate with you.
2、Question: Please, what is the product warranty? Thank You.
Answer: All Fiber Optic Transceivers share 3-year standard warranty.
3、Question：What Is Multimode SFP?
Answer：Multi-mode thread (MMF) uses a very large core and usually uses more wavelengths. Therefore, the optics used in the MMF has the ability to collect light from the laser. In practice, this means that the optics is cheaper. The generic multimodal SFP (MMF SFP) runs along the 850nm wavelength and is only used for a short distance transduction in the range of 100m to 500m. Although it cannot walk long distances, many types of optical alarms can be transported.
