40ch DWDM MUX/DEMUX（AAWG）Card
will be applied with DWDM OTN white box to transfer 40 channels wavelength capacity service
The HT6000-AAWG40 from HTF is a combined passive Forty-Channel 100GHz DWDM multiplexer and de-multiplexer (MUX & DEMUX). It combines standard 100GHZ DWDM ITU grid channels 21 through 60, and applies to 1U chassis,2U chassis and 5U chassis, occupying two service slots.
40ch mux demux function:
40 channel DWDM optical signal multiplexed into one fiber
40 channel optical signal de-multiplexer to single-wavelength signals
40ch mux demux Highlights:
40 Channel Multiplexer and Demultiplexer (MUX & DEMUX)
Plug and play: requires no configuration
Green product: completely passive, needs no power and no cooling
Low insertion loss, insertion loss ≤6dB, typ 4.5dB
Uniform insertion loss variation over the 40-channels - less than 1dB (typical 0.6dB)per MUX or DEMUX
High channel isolation
Adjacent isolation ≥25dB
Non-adjacent isolation ≥35dB
High reliability, MTBF of 100 years
Application with DWDM OTN white box:
More DWDM OTN white box info link with us:
