DWDM Telecom Solution HTF HT6000 is a compact, high-capacity, low-cost OTN optical transmission system which introduced by HTF. It adopts CWDM / DWDM common platform design, supports multi-service transparent transmission, and has flexible networking and access capabilities. Applicable to the national backbone network, provincial backbone network, metro backbone network and other core networks, to meet the needs of large-capacity nodes above 1.6T, is the industry‘s most cost-effective transmission application platform. Build a large-capacity WDM transmission expansion solution for IDC and ISP operators.
DWDM Telecom Solution specifications
Item | Description | |
Transmission capacity | 96x10Gbps /96x100Gbps | |
Network management unit | EMS network management disk | |
OTU | Support 1.25G ~10Gbps, 100Gbps | |
1/2/4/8 /10Gbps Fibre Channel | ||
CPRI;2/3/4/5/6/7 | ||
1G/10G Ethernet LAN or WAN PHY | ||
STM-4/16/64 SONET/SDH | ||
MUX/DEMUX | support 8ch/16ch/40ch/48ch | |
EDFA | EDFA erbium doped fiber amplifier | |
DCM | DCM:G.652/G655 Dispersion compensation fiber module | |
OLP | OLP1 + 1 optical protection | |
size | Services card | 20.5(H)× 195(W)× 252(D) (mm) |
1U 4-slot chassis | 482.5 ( W ) x 350( D ) x 44.5 ( H ) mm | |
2U 8-slot chassis | 482.5 ( W ) x 350( D ) x 89 ( H ) mm | |
5U 20-slot chassis | 482.5 ( W ) x 350( D ) x 222.5 ( H ) mm | |
Environment | Operating Temperature | -10℃ ~ 60℃ |
Storage Temperature | -40℃ ~ 80℃ | |
Relative humidity | 5% ~ 95% Non-condensing | |
Power supply mode | dual power supply, AC220V/DC-48V optional | |
Power consumption | 1U ＜120W, 2U＜200W, 5U＜400W | |
HT6000 DWDM Telecom Solution include the following cards
| NMS management card | 100G QSFP28 to CFP transponder | 2xQSFP28 to CFP2 200G Muxponder |
| 100G Muxponder: QSFP28 ↔ 4xSFP28 | 40G&100G OEO: 6*QSFP28 | SFP28 25G Quad transponder |
| SFP+ Multi-Rate Quad transponder | Redundant Multi-Rate Dual transponder | EDFA Optical Amplifiers |
| Bidi EDFA Optical Amplifiers | 16ch DWDM MUX/DEMUX | 40ch DWDM MUX/DEMUX（AAWG） |
| OLP Optical Line Protector | DWDM Passive Optical Add/Drop Multiplexers | DCM card |
How to customized the Active DWDM system according to our project?
Kindly send us the following necessary information, Then our engineers will design customized solution for you.
(1) Cable length, then can choose the DCM.
(2) optical fiber cable attenuation, configurate the EDFA.
(3) Data rate, configurate and choose the optical transceiver
(4) Channels. then can choose Mux/Demux
(5) Optical fiber cable is single fiber or dual fiber.
(6) Station number, How the business add and drop. Peer to peer, chain network or Ring network?
(7) In the middle if have optical amplifier station.
If you just need passive WDM mux demux solution, HTF team also can support you to save cost.
CWDM+CWDM SFP or DWDM+DWDM SFP solution
2~96Channels mux demux available.
Package: ABS plastic box, LGX metal cassette box, 19inch rack mount, CCWDM module type available.
HTF team would like share more information for you.
1. How to deploy a hybrid CWDM/DWDM network over fiber?
This could be achieved by connecting the 1530nm or 1550nm CWDM channel to the line port of DWDM Mux Demux.
CWDM 1530nm matches to narrowband C53-C60 of DWDM,
CWDM 1550nm matches to narrowband C27-C42 of DWDM.
2. Welcome to contact HTF team, you will get the free dwdm solution design and technical support.
You can get the following DWDM transmission solution example picture:
DWDM peer-to-peer case
DWDM chain network case
DWDM+OLP optical line protection Case
DWDM Ring network case
DWDM single fiber bidirectional networking case
DWDM ultra long distance solution
