fiber optic mode Transponder Card system telecom
Feature:
(1)3R signal regeneration
Retransmission
Reshaping
Retiming
(2)Multi-rate supports 1Gbps ~ 10Gbps
(3)Supports Loopback Test
(4)Supports LFP
(5)Flexible transmission of various protocols
Fibre Channel 1/2/4/8 /10Gbps
CPRI; 2/3/4/5/6/7
1G/10G Ethernet
SDH STM-4/16/64
Specifications
System parameters | Technical indicators | |
Center wavelength | Compliance with ITU-I standard | |
CWDM 1271 ~ 1611nm | ||
DWDM 1529.5~1565.50nm | ||
Data Rate (Gbps) | Fibre Channel: 1/2/4/8 /10Gbps | |
CPRI; 2/3/4/5/6/7 | ||
Ethernet: 1G/10G | ||
SONET: OC-24, OC-48, OC-192 | ||
SDH: STM-16/64 | ||
3R regeneration | Re-amplification, Re-shaping, Re-timing | |
Optical interface type | 8xSFP+ | |
NMS | TELNET, SNMP, WEB | |
Size | 20.5(W)× 195(H)× 252(D)mm | |
Environment | Operating Temperature | -10℃ ~ 60℃ |
Storage Temperature | -40℃ ~ 80℃ | |
Relative humidity | 5% ~ 95% Non-condensing | |
Power Consumption | ≤15W | |
HT6000-OTUQS2S Model Optional:
(1) 125Mbps~2.5Gbps Quad Multi-Rate transponder, Converter/Repeater, 8SFP interfaces with 3R
Client Side: SFP x4 Line Side: SFP x4
(2) 1.25G~10G Quad Multi-Rate transponder, Converter/Repeater, 8SFP+ interfaces with 3R
Client Side: SFP+ x4 Line Side: SFP+ x4
10G SFP+ Multi-Rate Quad Transponder/Repeater/Converter has 8 SFP+ slots, The device provides a flexible transmission of various protocols, such as 1G/10G Ethernet, SDH STM16/STM64, OTU1/OTU1e/OTU2/OTU2e, Fiber Channel 1/2/4/8/10, CPRI, etc.The SFP+ transponder supports multi-rate functionality with optical data rates from 1Gbps up to 10Gbps;The wide range of optical infrastructure solutions includes media conversion,signal repeating, lambda conversion.
The main field of application is CWDM and DWDM networks. As an intelligent transponder module,SFP+ Transponder converts a transparent data channel to a corresponding CWDM/DWDM wavelength. By means of the implemented 3R functionality (re-amplification, re-shaping, re-timing) for signal processing, the module is also suited for the use as a repeater,The SFP+ transponder models fit HT6000 series CH04、CH08、CH16 chassis
