SC SFP module fibre channel CWDM 80km 2.5G transceiver
Product Details
Model type | SFP-2.5G | Brand | HTF |
Encapsulation | SFP | Data Rate | 2.5Gb/s |
Power Supply Voltage | 3.3V | Reach | 80KM |
Interface | Duplex LC/UPC | LD | DFB |
Cable Type | SMF | DDM Support | Yes |
Tx power | <-45dBm | Rx Sens | <-28dBm |
Transmission Distance | 80km SMF | Quality guarantee | 3 years |
Recommended Operating Conditions and Power Supply Requirements
Parameter | Symbol | Min | Typical | Max | Unit | Notes |
Operating Case Temperature | TOP | 0 | 70 | oC | commercial | |
-10 | 80 | extended | ||||
-40 | 85 | industrial | ||||
Power Supply Voltage | VCC | 3.135 | 3.3 | 3.465 | V | |
Data Rate | 2.5 | Gb/s | ||||
Control Input Voltage High | 2 | Vcc | V | |||
Control Input Voltage Low | 0 | 0.8 | V | |||
Link Distance (SMF) | D | 80 | km | 9/125um |
FAQ:
Q：Is it compatible with Cisco switch?
A：This is good quality transceiver, fully compatible
Q：Can I use it in the data center?
A：Most data centers can be used with guaranteed quality.
Q：How about after sales?
A：We will have relevant personnel in charge of after-sales service. If you don't know anything, you can ask at any time
