Product Specifications
Connector A | MTP Female (pinless) | Connector B | MTP Female (pinless) |
Fiber Mode | OS2 9/125μm SM | Wavelength | 1310/1550nm |
Polish Type | APC to APC | Minimum Bend Radius | 10mm |
Insertion Loss | 0.35dB Max(0.15dB Typ.) | Return Loss | ≥60dB |
Attenuation at 1310nm | ≤0.32dB/km | Attenuation at 1550nm | ≤0.18dB/km |
Jacket OD | 3.0mm | Cable Jacket | Plenum (OFNP) |
Installation Tensile Load | 100 N | Long-Term Tensile Load | 50 N |
Operating Temperature | -10°C to +70°C | Storage Temperature | -40°C to +85°C |
Unique optical fiber channel is used for end connection to meet 40G/100G Ethernet. Supporting high broadband applications takes up the smallest physical space.
High-density solutions, with strong MPO/MTP product design and manufacturing capabilities, we can provide customers with a variety of customized products and solutions.
All jumpers are strictly tested before they leave the factory to ensure that the end surface is stainless, insertion loss and echo loss are in line with international telecommunications standards.
12 Fibers Elite MTP to LC Duplex MTP Fiber Optic Plug-N-Play Cassette, 12 Strands OM4 50/125μm MMF
MTP Fiber Cassette Modules offer 12-fiber MTP adapter on the rear of the units routed to duplex LC adapters on the front patch field, which interconnect with high-density fiber cable assemblies for quick connection of remote or data center applications.
MTP connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors.
FAQ
Q: Can the OM3 cable be used in OM4 MTP-12 Cassette?
A: Yes, OM4 can be downward compatible with the corresponding cable, but the transmission is limited by OM3 cable.
Q: What are your main products?
A: HTF supplies a broad range of communication solutions products including wavelength division multiplexer(WDM/CWDM/DWDM/OADM), Fiber Optic Transceivers(SFP, SFP+, XFP, 10G QSFP+, 40G QSFP+ and 100G CFP2), OEO Converter Repeater, Ethernet Media Converter, Fiber Optical Patch cord and Fiber Optical assembly.
Q: How could I ensure the cable's quality?
A: We have our own QC control department, and we also have got many certifications such as CE, ROHS and so on to ensure the quality of our products, you could just trust us.
Q: Are you factory or foreign trade company?
A: We are factory and we do trading too, we will provide you with the most competitive goods and products.
