Product Introduction:

HT-OSW-1×2 Optical Switch, which is famous for its high performance, low insertion loss and compact dimension: (L)27.0×(W)12×(H)8.2mm. It is an ideal component for OADM，OXC，system monitoring and protection. With compact package, it can be easy to integrate into a high density optical communication system.

Send Inquiry

Description

Technical Parameters

multi mode single mode Fiber Optical Switch 1 In 2 Port

HT-OSW-1×2 Optical Switch is an ideal component for OADM，OXC，system monitoring and protection. With compact package, this optical switch can be easy to integrate into a high density optical communication system.

Features

Low Insertion Loss
Wide Wavelength Range
Low Crosstalk
High Stability, High Reliability

Applications

R&D in Laboratory
System Monitoring
OADM
MAN (Metropolitan Area Network)

Optical Switch Specifications

1x2 optical switch

Type	State	Optical Route	Electric Drive	State Sensor
1x2			Pin 1	Pin 5	Pin 6	Pin 10	Pin 2-3	Pin 3-4	Pin 7-8	Pin 8-9
Latching	A	P1-P2	-		GND	V+	Close	Open	Open	Close
B	P1-P3	V+	GND		-	Open	Close	Close	Open
Non-latching	A	P1-P2	-				Close	Open	Open	Close
B	P1-P3	V+	-	-	GND	Open	Close	Close	Open
