Single mode fiber transceiver 10G SFP 10km LR BIDI
Model type | SFP-10G-BIDI-10KM | Brand | HTF |
Encapsulation | SFP+ | Data Rate | 11.1Gb/s |
Wavelength | 1270nm-TX/1330nm-RX；1330nm-TX/1270nm-RX | Reach | 10KM |
Cable Type | SMF（9/125µm） | Interface | BIDI LC optical connector |
Protocols | SFF-8472 MSA compliant &SFF-8431;MSA Compliant | Optical Components | DFB BIDI |
Tx power | -6~-1dBm | Rx Sens | <-14.4dBm |
Commercial Temperature Range | 0 to 70°C (32 to 158°F) | Applications | Back to Back 10GBASE-ER/EW 10G Ethernet |
Features
◆1270nm DFB laser and PIN receiver for HTSX-B273396Lx
◆1330nm DFB laser and PIN receiver for HTSX-B332796Lx
◆2-wire interface with integrated Digital Diagnostic monitoring
◆Single +3.3V power supply
General Description
The SFP+ MSA defines a 256-byte memory map in EEPROM that is accessible over a 2-wire serial interface at the 8 bit address 1010000X (A0h). The digital diagnostic monitoring interface makes use of the 8 bit address 1010001X (A2h), so the originally defined serial ID memory map remains unchanged.
Where is the bidirectional optical module of BIDI applied?
Single fiber Bidirectional is usually used for user access network to complete image and data, voice and other communication at low cost.
FAQ
1、Question：Will this work with 1g (not 10g) sfp ports in Cisco switches?
Answer：Yes. As long as the rate of both ends are consistent.
2、Question：Wills it Compatibility with Huawei?
Answer：Yes, it will.
3、Question：What is the best method to make fiber runs with SFP connectors 100M+?
Answer：Making fiber runs with SFP and distance over 100m is easy to reach. Both single-mode SFP and multi-mode SFP transceivers can meet the requirement. It's all depends on your actual need.
