Multimode SFP with single mode fiber BIDI 622M 160km Module
Model type | SFP-622M-BIDI-160KM | Brand | HTF |
Encapsulation | SFP | Data Rate | 622M |
Wavelength | 1550nm-TX/1490nm-RX 1490nm-TX/1550nm-RX | Reach | 160KM |
Cable Type | SMF（9/125µm） | Interface | BIDI LC optical connector |
Tx power | 1~6dBm | Rx Sens | <-33dBm |
Protocols | SFF-8472 MSA compliant &SFF-8431;MSA Compliant | Optical Components | 1550nm DFB laser transmitter and APD photo-detector |
Part Number Ordering Information
Part Number | Data Rate (Mb/s) | Wavelength (nm) | Transmission Distance(km) | Temperature (oC) (Operating Case) |
HTSF-B6M5549YC | 622 | 1550Tx/1490nmRx | 160km SMF | 0~70 commercial |
HTSF-B6M5549YE | 622 | 1550Tx/1490nmRx | 160km SMF | -10~80 Extended |
HTSF-B6M5549YI | 622 | 1550Tx/1490nmRx | 160km SMF | -40~85 Industrial |
What are the causes of poor power of optical transceiver?
(1). Power does not match with resistance
(2). Defective patch or poor performance of drive chip
(3). Poor transmitter TOSA or PD+ pin solder joint false
(4). Magnetic beads on LD+ and LD- signal lines are defective or missing
(5). The components (capacitance, resistance, inductance or magnetic bead) at the foot of the storage chip are defective or missing
FAQ
1、Question: Is it possi le to order 400 to 500 of these??
Answer: Of course! Please contact us at "sales2@htfuture.com", we will offer you a reduced price for this bulk order. Look forward to cooperate with you.
2、Question: Does it works with any fiber cable such as om1, om2, om3, om4 multimode fiber cables?
Answer: Yes, OM1, OM2, OM3, OM4 LC to LC duplex multimode fiber cables can all work with this module.
