SFP transceiver multimode om4 SFP SFP+ LR 1310nm
General Description
|
Model type |
SFP-10G-LR |
Brand |
HTF |
|
Encapsulation |
SFP+ |
Data Rate |
11.3Gb/s |
|
Wavelength |
1310nm |
Reach |
10km |
|
Interface |
Duplex LC |
LD |
DFB |
|
Cable Type |
SMF |
DDM Support |
Yes |
|
Tx power |
-6~-0.5dBm |
Rx Sens |
-14.4dBm |
|
Temperature |
0~70°C (32~158°F) |
Quality guarantee |
3 years |
Features
● 1310nm DFB transmitter and PIN receiver
● Up to 10km on 9/125µm SMF
● Hot-pluggable SFP+ footprint
● Duplex LC/UPC type pluggable optical interface
● RoHS compliant and lead-free
Applications
● 10GBASE-LR/LW & 10G Ethernet
● SDH STM64
● Other Optical Links
Recommended Operating Conditions and Power Supply Requirements
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
Notes |
|
Operating Case Temperature |
TOP |
0 |
|
70 |
℃ |
commercial |
|
-40 |
|
85 |
℃ |
Industrial |
||
|
Power Supply Voltage |
VCC |
3.135 |
3.3 |
3.465 |
V |
|
|
Data Rate |
|
|
10.3125 |
|
Gb/s |
|
|
Control Input Voltage High |
|
2 |
|
Vcc |
V |
|
|
Control Input Voltage Low |
|
0 |
|
0.8 |
V |
|
|
Link Distance (SMF) |
D |
|
|
10 |
km |
9/125um |
Mechanical Dimensions
FAQ
1. Question: Is it a replacement part for a Gigamon fclf-8520-3-gm?
Answer: No, it isn't. According to our experience, Finisar switch do not have special requirements for coding.
2. Question: Will this work with Cisco?
Answer: Yes, it will.
3. Question: Is it possi le to order 400 to 500 of these??
Answer: Of course! Please contact us at "sales2@htfuture.com", we will offer you a reduced price for this bulk order. Look forward to cooperate with you.
