Optical Transceiver Module MPO Connector 200G QSFP56 SR4 100m

200G QSFP56 SR4 100m Transceiver is a high-speed transmission optical module. It has the following advantages and applicable environments:

1. High-speed transmission: 200G QSFP56 SR4 100m Transceiver has a transmission speed of up to 200G, which can easily meet the needs of application scenarios such as high-speed data centers, cloud computing, and data communications.

2. Long-distance transmission: 200G QSFP56 SR4 100m Transceiver can perform long-distance transmission within a range of 100 meters, and is suitable for long-distance transmission in data centers, enterprises and computer networks.

3. High reliability: 200G QSFP56 SR4 100m Transceiver uses high-quality materials and precise manufacturing processes, which has high reliability and stability, ensuring the success rate and stability of data transmission.

4. Hot-swappable: 200G QSFP56 SR4 100m Transceiver supports high-speed hot-swappable function, which can easily and quickly replace and maintain optical modules, improving the reliability and availability of the equipment.

200G QSFP56 SR4 100m Transceiver is suitable for the following application environments:

1. High-speed data center: 200G QSFP56 SR4 100m Transceiver can meet the needs of high-speed data centers, such as data storage, server clusters, cloud computing, etc.

2. Computer network: 200G QSFP56 SR4 100m Transceiver can be used for high-speed transmission of computer networks, such as LAN, WAN, etc.

3. Enterprise network: 200G QSFP56 SR4 100m Transceiver can be suitable for high-speed transmission of enterprise networks, such as backbone networks, branch networks, etc.

In short, 200G QSFP56 SR4 100m Transceiver has the advantages of high-speed transmission, long-distance transmission, high reliability and hot-swappability, and is suitable for a variety of high-speed data transmission fields.


Features

• Compliant with 200G-SR4 optical specifications

• 4x53.125Gb/s electrical interface (200GAUI-4)

• Reach up to 70m on MMF(OM3)

• Reach up to 100m on MMF(OM4)

• Single +3.3V power supply

• Case temperature range: 0 ~ +70℃

• Maximum power consumption 4W

• Single MPO12 connector

• RoHS complaint

Applications

• 200G BASE-SR4 Ethernet links

• Data centers

Standards

• IEEE 802.3cd

• SFF 8679

• CMIS4.0 or SFF8636
