In the era of information construction, high-density data centers are the basic needs of large enterprises. In order to meet the needs of data centers for high efficiency, economy, low loss, and space saving, and the simplification of multi-floor high-density wiring (since large enterprises are all Building office, so it involves multi-floor wiring), we can use fiber optic jumpers to connect the wall-mounted fiber optic distribution box and high-density fiber distribution box, making wiring more convenient, while saving space wiring.
How to use MTP/LC/MTP-LC different types of fiber jumpers to connect MTP/MPO high-density fiber distribution boxes, MTP fiber adapter panels, high-density fiber distribution boxes, and wall-mounted fiber distribution boxes when wiring in large enterprises What about equipment? The specific connection method is as follows:
1. Place 2 fiber distribution boxes in the 1U rack-type fiber distribution box, then insert the optical module into the corresponding port of the switch, and finally connect the switch with LC single-mode fiber jumpers
2. Place two MTP fiber adapter panels in a wall-mounted fiber distribution box, and then use MTP fiber jumpers to connect the fiber distribution box to the fiber adapter panel
3. Place multiple fiber distribution boxes (the number depends on the demand) in a high-density fiber distribution box (to meet the needs of high-density data centers), and then use MTP fiber jumpers to connect the fiber adapter panel to the fiber distribution box
4. Use ultra-low loss LC fiber jumpers to connect to the server
