What are the advantages of LC Uniboot compared to conventional LC fiber optic connectors?
Ordinary LC dual-core connectors are generally composed of two LC single-core connectors through clips, and each connector contains a single optical fiber. The LC Uniboot connector is an improved LC dual-core connector. Two optical fibers are simultaneously in a 2.4mm or 3.0mm sheath to achieve the function of a single tube and dual core, which can significantly reduce the space requirement for wiring. So what is the difference between the LC uniboot connector and the conventional LC fiber optic connector?
Compact design to meet the needs of high-density applications. LC Uniboot uses a dual-fiber single tube and integrated tail sleeve design to eliminate the need for double-stranded cables. It is more compact and saves space than ordinary LC duplex fiber jumpers, reducing 50% % Of the overall bulk wiring. At the same time, it is conducive to heat dissipation of the wiring system, and more reasonable utilization to achieve greater energy efficiency.
The polarity can be switched, and the operation is simple and convenient. What is the fiber polarity? The fiber polarity is the direction in which the optical signal propagates in the fiber. Normally, there are the sending signal end (Tx) and the receiving signal end (Rx). The LC Uniboot optical fiber connector innovatively sets the two plugs of the optical fiber connector into a mutually interchangeable design, which helps users to easily reverse the polarity of the optical fiber, and can easily open the ferrule and switch the polarity without any tools.
What are the advantages of LC Uniboot compared to conventional LC fiber optic connectors?
The innovative LC uniboot optical fiber connector, with its unique structure and compact design, performs better than conventional LC dual-core connectors in a high-density wiring environment, and is an ideal choice for data centers and FTTX.
