Patch Cord MTP LC Duplex OM3 OFNP Aqua 3ft cable
What are the benefits of using MTP-LC branch jumpers?
When designing a network system, it is very important to plan the structured cabling in advance. Our goal is to solve the current network needs and adapt to the future development. With the development of network, structured cabling system can flexibly handle the task of executing mobile, adding or changing infrastructure. Using MTP-LC branch jumpers in high-density LANs or storage switches can help you improve structured cabling.
Features
Optional 8-12 cores
Cross connection: AB / BA
Parallel connection: AB / AB
Small size and easy to manage
A variety of loss indexes can be selected
ROHS compliant
Specifications
Advantages of MPO / MTP cable
(1) Because of its small size, the diameter of the wiring hole can be increased, thus greatly improving the wiring density and saving space.
(2) Modular design, plug and play, save installation time.
(3) According to different configuration requirements, the corresponding structure can be selected to meet different wiring requirements.
(4) It has excellent optical and mechanical properties and low insertion loss in high-speed network environment.
Notes on MPO / MTP cable
1. When the MPO / MTP optical fiber jumper is not connected, do not pull out the dust cap of the jumper in advance, so as to prevent contamination and damage to the jumper end face.
2. In MPO / MTP optical fiber wiring, do not let the MPO / MTP fiber connector end touch anything, otherwise it will cause excessive loss of optical fiber link. If you accidentally touch the end face of MPO optical fiber connector, please clean it with MPO cleaner before docking.
3. During MPO / MTP fiber wiring, do not pull or squeeze the optical fiber jumper vigorously to avoid damage to the optical fiber jumper.
4. When docking MPO / MTP optical fiber connector, it means that the butt joint is in place only when the "click" sound is heard. Otherwise, it is necessary to plug and plug it again.
