Patch Cord network patch cable 8 Fibers MTP-LC OS2

MTP cables can be divided into different types: Polarity A, Polarity B and Polarity C.

The most commonly used MTP trunk cable is a single strand of cable, which can provide duplex 40G transmission at the same time. There are also MTP trunk cables which are composed by several strands of cables.

12-Fiber MTP Harness Cable: MTP harness cable is a length of fanout cable with one end terminated with MTP connector and the other end terminated with several connectors like LC and SC. 12-fiber MTP harness cables also come in a variety of types according to fiber type, polarity type and connector types.

12-Fiber MTP Cassette: MTP cassette is like MTP harness cable which also provides the transferring between MTP interface and LC or SC interfaces. But MTP cassette can protect the fragile optical fibers inside the metal box, and has lower space requirements than MTP harness cable.

Specifications

Parameters	Unit	Values
Fiber Mode	-	OS2 SMF 9/125μm
MTP Connector IL	dB	0.35dB Max(0.15dB Typ.)
MTP Connector RL	dB	≥60
Attenuation at 1310nm	dB/km	≤0.32
Jacket OD	mm	3.0
Installation Tensile Load	N	100
Cable Jacket	-	Plenum (OFNP)
Operating Temperature	°C	-10 ~ +70
Wavelength	nm	1310/1550
LC Connector IL	dB	≤0.2
LC Connector RL	dB	≥50
Attenuation at 1550nm	dB/km	≤0.18
Fan-Out Diameter	mm	2.0
Long-Term Tensile Load	N	50
Fiber Count		8 Fibers
Storage Temperature	℃	-40 ~ +85

High Performance MTP Cabling Solution

MTP optical fiber jumpers are usually used to connect optical fiber modules, MTP optical fiber wiring boxes and optical fiber adapter panels, so as to provide strong network flexibility for data center wiring.

MTP line brings many conveniences for enterprise engineering implementation through the implementation of end-to-end high-density integration and plug-and-play.
