Features

● Up to 11.3Gb/s data links

● DWDM EML transmitter and APD photo-detector

● 100 GHz ITU channel spacing with integrated wavelength locker

● Up to 80km on 9/125µm SMF

● with CDR supported 9.95 to 11.3Gb/s reference-free

● Duplex LC/UPC type pluggable optical interface

● Support Digital Diagnostic Monitoring interface

● Metal enclosure, for lower EMI

● RoHS compliant and lead-free

● Hot-pluggable SFP+ footprint

● Single +3.3V power supply

● Compliant with SFF+MSA and SFF8472

● Case operating temperature

Commercial: 0 ~ +70℃

Extended: -10 ~ +80℃

Industrial: -40 ~ +85℃

Ordering information

Part Number	Data Rate (Gb/s)	Wavelength (nm)	Transmission Distance(km)	Temperature (^oC) (Operating Case)
HTSX-1DCxx96ZC	10.3125	Refer to wavelength selection	80km SMF	0~70 commercial
HTSX-1DCxx96ZE	10.3125	Refer to wavelength selection	80km SMF	-10~80 Extended
HTSX-1DCxx96ZI	10.3125	Refer to wavelength selection	80km SMF	-40~85 Industrial

Optical Characteristics

Parameter	Symbol	Min.	Typical	Max	Unit	Notes
Transmitter
Optical Wavelength	λc	λc -0.1		λc +0.1	nm	1
Center Wavelength Spacing			100		GHz
Optical Spectral Width	∆λ			1	nm
Side Mode Suppression Ratio	SMSR	30			dB
Average Optical Power	P_AVG	0		4	dBm	2
Optical Extinction Ratio	ER	6			dB
Transmitter and Dispersion Penalty	TDP			3	dB
Transmitter OFF Output Power	POff			-30	dBm
Relative Intensity Noise	RIN			-128	dB/Hz
Transmitter Eye Mask		Compliant with IEEE802.3ae
Receiver
Center Wavelength	λ_C	1480		1580	nm
Receiver Sensitivity (Average Power)	Sen.			-24	dBm	3
Input Saturation Power (overload)	Psat	-6			dBm
LOS Assert	LOSA	-35			dB
LOS De-assert	LOSD			-26	dBm
LOS Hysteresis	LOSH	0.5			dBm
