General Description
Model type | SFP-10G-ER | Brand | HTFuture |
Encapsulation | SFP+ | Data Rate | 11.3Gb/s |
Wavelength | 1550nm | Reach | 40km |
Interface | Duplex LC | LD | EML |
Cable Type | SMF | DDM Support | Yes |
Tx power | -1~3dBm | Rx Sens | --15.8dBm |
Temperature | 0~70°C (32~158°F) | Quality guarantee | 3 years |
Features
● Up to 11.3Gb/s data links
● 1550nm EML transmitter and PIN receiver
● Up to 40km on 9/125µm SMF
● Hot-pluggable SFP+ footprint
● Duplex LC/UPC type pluggable optical interface
● Metal enclosure, for lower EMI
● RoHS compliant and lead-free
● Support Digital Diagnostic Monitoring interface
● Single +3.3V power supply
● Maximum power consumption 1.5W
● Compliant with SFF+MSA and SFF8472
● Case operating temperature
Commercial: 0 ~ +70oC
Extended: -10 ~ +80oC
Industrial: -40 ~ +85oC
Applications
● 10GBASE-ER/EW & 10G Ethernet
● SDH STM64
● Other Optical Links
Mechanical Dimensions
FAQ
1. Question: Will this work with Cisco?
Answer: Yes, it will.
2. Question: Will this work with 62.5 and 50 micron both?
Answer: Yes they will.
3. Question: Does this work with 50/125 cable with LC connectors?
Answer: Yes
4. Question: Please, what is the product warranty? Thank You.
Answer: All Fiber Optic Transceivers share 3-year standard warranty.
5. Question: What Is SFP？
Answer: When we discuss what SFP is, SFP stands for Small Form-Factor Pluggable, a compact, hot-pluggable transceiver that can be used in the ports of telecommunications and data communications equipment. SFP modules are designed to support SONET, Gigabit Ethernet, Fiber Channel and other optical communication standards. Due to its small size and improved performance in conjunction with higher speeds, the module has displaced the universally applicable GBIC transceivers and is therefore sometimes referred to as a mini-GBIC.
As an interchangeable fiber connector that can adapt to any existing network, SFP makes network maintenance a lot easier. SFP transceiver modules allow a higher port density (number of transceivers per cm along the edge of a motherboard). These modules are not standardized by a state agency, but specified by a multi-source agreement (MSA), which has been adopted by various manufacturers. Some network component manufacturers have provided protection to the SFPs, deliberately avoiding compatibility with generic "SFPs" by checking firmware or other areas of programming, whereby only the modules approved by the manufacturer can be used. However, some manufacturers have introduced SFPs with empty programmable EEPROMs that can be reprogrammed to match each supplier ID.
Modern SFP transceiver modules also come with standard Digital Diagnostic Monitoring (DDM) functions, which is also known as Digital Optical Monitoring (DOM). This gives end users the ability to monitor in real time SFP parameters such as optical output, optical input power, temperature, laser current, supply voltage, etc. This functionality can be used to monitor routers, switches, and other optical devices, which can be reprogrammed to match any supplier ID.
